Ruud RCFY3617STANMC Cased Coil R454B

Product Description

The RUUD RCFY3617STANMC is a cased furnace coil designed for use with R454B refrigerant. It features aluminum fins bonded to internally grooved aluminum tubing, copper sweat refrigerant connections, and a TXV metering device. It is compatible with a germicidal light system and approved for system application with a variety of Rheem outdoor units.

• Constructed of Aluminum Fins Bonded to Internally Grooved Aluminum Tubing
• Coils are Tested at the Factory with an Extensive Refrigerant Leak Check
• Coils have Copper Sweat Refrigerant Connection

Product Highlights

This cased furnace coil features bi-directional airflow, a unique drain pan design, and an N-Coil design for maximized performance and minimized installation height.

Product Information

Standard Information

• Brand: RUUD
• Manufacturer Part Number: RCFY3617STANMC

Technical Specifications

• Application: Cased Furnace Coil
• Tonnage: 3
• Refrigerant Type: R454B
• Cabinet Width (Inches): 17.5
• Efficiency: Standard
• Casing: Cased
• Connections Liquid/Suction (Inch): 3/8 / 3/4
• Metering Device: TXV
