Ruud RACL2120DBZ Split Condenser 10 Ton 460V 3-phase

Product Description

The RUUD RACL2120DBZ is a 10-ton split-system condenser designed for commercial air conditioning applications operating on 460-volt, 3-phase power. With a gross cooling capacity of 120,000 BTU/h, this unit serves as the outdoor section of a split A/C system, rejecting heat from the refrigerant circuit to the ambient air. Licensed HVAC technicians and commercial refrigeration mechanics install and service this class of equipment in multi-zone and large-area cooling applications. The 460-volt, 3-phase electrical configuration is typical of light commercial and industrial facilities with dedicated three-phase electrical service.

The RACL2120DBZ is suited for commercial split air conditioning installations where a high-capacity outdoor condenser is required. Its 10-ton nominal rating makes it appropriate for light commercial buildings, retail spaces, warehouses, and similar applications requiring sustained cooling loads. This unit pairs with a compatible evaporator coil and air handler to complete the split-system refrigerant circuit. Installation is performed by licensed commercial HVAC contractors familiar with 460-volt 3-phase equipment and commercial refrigerant systems.

Key Features

• 120,000 BTU/h gross cooling capacity for high-demand commercial environments
• 10-ton nominal cooling rating suitable for large commercial spaces
• 460-volt, 3-phase electrical configuration for facilities with commercial power service
• Split condenser design pairs with a matched evaporator and air handler

Compatibility

Designed as an OEM split-system condenser for commercial 3-phase air conditioning installations requiring a 10-ton outdoor condensing unit rated at 460 volts.

Installation Notes

Installation must be performed by a licensed HVAC technician certified to handle refrigerants under applicable EPA Section 608 requirements. Disconnect and lock out all electrical power before any service work. The 460-volt 3-phase electrical supply must be sized, protected, and wired in accordance with the NEC and local codes. Verify refrigerant line sizing, evacuation, and charge procedures follow manufacturer specifications and industry standards before commissioning.

Technical Specifications

• Item Type: Split Condenser
• Nominal Capacity: 10 Tons
• Gross Cooling Capacity: 120,000 BTU/h
• Voltage: 460 volts
• Phase: 3-Phase

Standard Information

• Brand: RUUD
• Manufacturer Part Number: RACL2120DBZ
