Trane A5AHC007A1D30A Convertible Air Handler 42000-60000 Btu/h 3.5-5 Ton R-454B Multi-position

Product Description

The Trane A5AHC007A1D30A is a multi-position convertible air handler rated for 3.5 to 5 ton capacity, delivering 42,000 to 60,000 BTU/h. It is designed for split-system cooling and heat pump applications using R-454B refrigerant and features an all-aluminum plate fin indoor coil with a factory-installed TXV refrigerant control. The unit operates on 208-230/1/60 power and supports 24-volt system control wiring. A PSC blower motor rated at 3/4 to 1 horsepower and 1050 RPM handles airflow duties. Licensed HVAC technicians install this unit as the indoor component of a split-system package.

The A5AHC007A1D30A is suited for residential cooling and heat pump systems in the 1,750 to 3,000 square foot range. Its 4-way poise design allows installation in upflow, downflow, horizontal left, or horizontal right configurations, making it adaptable to closets, utility rooms, alcoves, basements, crawlspaces, and attics. The unit is compatible with optional electric heater kits including BAYHTR1504BRK, BAYHTR1504LUG, BAYHTR1505BRK, BAYHTR1505LUG, BAYHTR1508BRK, BAYHTR1508LUG, BAYHTR1510BRK, BAYHTR1510LUG, BAYHTR3510LUG, BAYHTR1517BRK, BAYHTR3517LUG, BAYHTR1523BRK, and BAYHTR1525BRK.

Key Features

• 4-way multi-position installation: upflow, downflow, horizontal left, horizontal right
• All-aluminum plate fin indoor coil rated for R-454B refrigerant
• Factory-installed TXV refrigerant control for accurate superheat management
• 24-volt system control interface compatible with standard split-system thermostats
• Blower motor rated 3/4 to 1 HP at 1050 RPM with multiple speed taps
• Compatible with a range of optional electric heater kit accessories

Compatibility

The A5AHC007A1D30A is designed for use with R-454B split-system condensing units. It has been paired with the A5AC5060A1000 outdoor condensing unit in a 5-ton, 15.2 SEER2 system configuration. Compatible optional heater kits include BAYHTR1504BRK, BAYHTR1504LUG, BAYHTR1505BRK, BAYHTR1505LUG, BAYHTR1508BRK, BAYHTR1508LUG, BAYHTR1510BRK, BAYHTR1510LUG, BAYHTR3510LUG, BAYHTR1517BRK, BAYHTR3517LUG, BAYHTR1523BRK, and BAYHTR1525BRK.

Installation Notes

Installation must be performed by a licensed HVAC technician familiar with R-454B refrigerant handling and EPA Section 608 requirements. Disconnect and lock out all electrical power to the system before beginning installation or service. Refrigerant line connections at the indoor coil are braze-type with a 3/8-inch liquid line and 7/8-inch gas line; follow standard brazing procedures and leak-check all joints before evacuation and charge. Verify unit orientation and confirm condensate drain connections are properly trapped for the selected installation position before startup.

Technical Specifications

• Capacity Range: 42,000-60,000 BTU/h (3.5-5 ton)
• Refrigerant: R-454B
• Voltage / Phase / Frequency: 208-230/1/60
• Full Load Amps: 6.0 amps
• Motor Horsepower: 3/4 to 1 HP
• Motor Speed: 1050 RPM
• System Control Voltage: 24 volts
• Indoor Coil Type: All-aluminum plate fin
• Coil Rows / Fins Per Inch: 4 rows / 14 FPI
• Refrigerant Control: TXV (factory installed)
• Liquid Line Connection: 3/8-inch braze
• Gas Line Connection: 7/8-inch braze
• Installation Positions: 4-way multi-position
• Unit Height (A): 57.40 inches
• Unit Width (B): 23.50 inches
• Unit Depth (C): 21.50 inches

Standard Information

• Brand: Trane
• Manufacturer Part Number: A5AHC007A1D30A
