Rotor Clip A-040 External Retaining Ring Applicator

Product Description

The ROTOR CLIP A-040 is an external retaining ring applicator designed for installing radial retaining rings on shafts and housings. The tool features a 0.265-inch blade width and a 1.438-inch blade length, providing the reach and precision needed for accurate ring placement in tight assemblies. The tips are heat treated for extended service life under repeated use. This applicator is sized for use with E-6 series external retaining rings and is a standard hand tool for assembly technicians, machinists, and maintenance professionals working in industrial or mechanical service environments.

This applicator is suited for assembly line work, field maintenance, and repair applications where external retaining rings must be installed or removed from shafts. The tool is designed for radial retaining ring styles and is not tether capable, making it appropriate for bench work and controlled assembly environments. It is packaged as a single unit and ordered individually. Facilities operating under ISO 13485:2016 quality management standards will find this tool compliant with those documentation and traceability requirements.

Key Features

• Designed for E-6 series external retaining rings on shafts and cylindrical components
• Heat treated tips for durability under repeated installation cycles
• Blade width of 0.265 inches and blade length of 1.438 inches for precise ring seating
• Tip length of 0.375 inches for controlled ring engagement
• Meets ISO 13485:2016 standards for quality management system compliance
• Single-piece tool, not tether capable — intended for controlled work environments

Compatibility

Designed for use with E-6 series external radial retaining rings. Consult ROTOR CLIP ring sizing charts to confirm shaft diameter and ring series compatibility before use.

Installation Notes

This tool is typically used by assembly technicians and mechanical maintenance professionals. Before installing retaining rings on any shaft in a live system, power down all rotating equipment and depressurize any associated lines or pneumatic circuits. Ensure the correct ring series and shaft groove dimensions match the applicator tip size to avoid ring deformation or improper seating. Always wear appropriate eye protection when installing or removing snap rings, as rings under tension can release unexpectedly.
