Robertshaw RBFD-083S Filter Drier 8 cu. in.

Product Description

The Robertshaw RBFD-083S filter drier is engineered to remove moisture and contaminants from refrigerants. This unit is compatible with multiple refrigerants, including R-12, R-134A, R-22, R-290, R-404A, R-407C, R-410A, R-500, R-502, and R-507. The filter drier is rated for one to fifty tons and features a leak-free construction, ensuring the integrity of refrigeration systems.

• Stops contaminants from entering the system
• Removes moisture effectively
• Protects sensitive system components

Product Highlights

This filter drier is suitable for residential and commercial HVAC applications.

Product Information

Standard Information

• Manufacturer Name: Robertshaw
• Product Type: Filter Drier

Technical Specifications

• Flow: Bi
• Capacity: 8 cu. in.
• Fitting Type: ODF
• Fitting Size: 3/8 inches
• Dimension A: 5.04 inches
• Dimension B: 3.78 inches
• Dimension C: 2.50 inches
• Dimension D: 3.54 inches
• Operating Pressure: 0 to 680 psi (0 to 47 bar/4.7 MPa)
• Temperature Range: -40 °C to 70 °C (-40 °F to 158 °F)
• Compatible Fluids: R22, R134A, R404A, R407C, R410A, R502, R507, R290
• Desiccant Type: Solid core (80% desiccant, 20% activated alumina)
• Model Number: RBFD-083S
• Brand: Ranco
