ROBERTSHAW 200-406 Thermostat

Product Description

The ROBERTSHAW 200-406 thermostat is suitable for residential and light commercial heating and cooling systems. This model offers a sealed-in-glass switch mechanism that prevents contamination and eliminates the need for leveling during setup.

• Compatible with 24-volt heating and cooling systems.
• Includes a decorative wall plate for covering mounting marks.
• Mercury-free and compliant with environmental safety standards.

Product Highlights

This thermostat ensures reliable performance and easy installation.

Product Information

Standard Information

• Brand: ROBERTSHAW
• MPN: 200-406

Technical Specifications

• Temperature Range: 39 to 65 degrees Fahrenheit
• Electrical Rating (24 Volt Models): 30 VAC max., 1.0 Amp max.
• Electrical Rating (Millivolt Models): 250 to 750 millivolts
• Differential: 2 degrees Fahrenheit (nominal)
• Switch Action: SPST
• Heat Anticipation Range (24 Volt Heating): 0.18 to 1.0 Amps
• Dimensions: 2-13/16 inches rounded square, 1-5/16 inches deep
