Rivetking /XPM312014SN/P100 Split Rivet Dome Head 100 Pack

Product Description

The RIVETKING /XPM312014SN/P100 is a dome-head split rivet manufactured from nickel-plated steel. Split rivets are two-pronged fasteners that install by spreading the prongs on the blind side of a workpiece, creating a secure mechanical lock without requiring a separate backing component. This rivet accepts hole diameters from 0.1 to 0.17 inches and features a 0.3125-inch head diameter with a 7/16-inch length under the head and a 9/64-inch body diameter. The nickel plating provides a corrosion-resistant finish suited to both indoor and light-duty moisture-exposed applications. Supplied in a package quantity of 100 pieces.

Split rivets with dome heads are commonly used in light-gauge sheet metal, leather goods, fabric, and non-structural panel fastening applications. They are a standard choice in HVAC duct liner attachment, electrical panel trim, and general sheet goods assembly where a finished, rounded head appearance is required on the face side. The compact body diameter and modest grip range make them appropriate for thin-material stacking typical in residential and light commercial trade work.

Key Features

• Dome head profile provides a clean, low-profile finished appearance on the face side
• Nickel-plated steel construction offers corrosion resistance over a bare steel base
• Hole diameter range of 0.1 to 0.17 inches accommodates thin-gauge material tolerances
• 0.3125-inch head diameter distributes clamping load across the workpiece surface
• Split-prong design installs without a rivet nut or backing hardware
• Packaged in quantities of 100 for shop and field use

Compatibility

Designed for use in applications requiring a dome-head split rivet with a hole diameter range of 0.1 to 0.17 inches and a 9/64-inch body diameter in nickel-plated steel.

Installation Notes

Split rivets are installed by inserting the body through a pre-drilled or punched hole and spreading the prongs on the reverse side using a setting tool or awl. Power down any associated equipment before fastening into panels or enclosures. Ensure hole diameter falls within the 0.1 to 0.17 inch grip range for a secure set. Avoid over-spreading the prongs, as this can fracture the body or reduce clamping strength.
