Rivetking /SBS818CM/SET/P10 Blind Rivet 8-18 Steel 10 Pack

Product Description

The RIVETKING /SBS818CM/SET/P10 is a flush-on-both-sides blind rivet designed for applications where a smooth surface finish is required on the installed side as well as the shop head side. Built with a steel body and steel mandrel, this dome head rivet carries a size code of 8-18, a body diameter of 0.25 inches, and a grip range of 0.875 to 1.125 inches. It is installed by a licensed mechanic, maintenance technician, or sheet-metal fabricator working in structural, HVAC panel, enclosure, or general fastening applications where access is limited to one side of the workpiece.

This rivet suits residential and commercial applications including ductwork fabrication, equipment enclosures, metal panels, and general sheet-metal assembly where a flush finish on both the driven and blind sides is required. The minimum hole diameter for installation is 0.255 inches. The 5/8-inch head diameter and 0.10-inch head height keep the installed profile low. This package contains 10 rivets with a minimum order quantity of 1 package.

Key Features

• Flush on both sides design delivers a smooth surface on the shop head and installed side
• Dome head profile with 5/8-inch head diameter and 0.10-inch head height
• Steel body and steel mandrel for reliable holding strength in metal-to-metal applications
• Size 8-18 with a grip range of 0.875 to 1.125 inches accommodates a range of material stack thicknesses
• Body diameter of 0.25 inches fits a 0.255-inch minimum hole diameter
• Packaged in quantities of 10 for job-site or bench use

Compatibility

Designed as a standard blind rivet for use in sheet-metal, ductwork, and equipment-enclosure assemblies requiring a flush finish on both sides; compatible with standard rivet installation tools sized for a 0.25-inch body diameter.

Installation Notes

Install with a pneumatic or manual blind rivet tool sized for a 1/4-inch body diameter. Drill or punch the mating hole to a minimum diameter of 0.255 inches before setting the rivet. Deburr the hole and ensure mating surfaces are clean and properly aligned before pulling the mandrel. Follow applicable OSHA and facility safety protocols when working with pneumatic tools or overhead installations.
