Rivetking SBS64/STR/P100 Structural Blind Rivet Size 64

Product Description

The RIVETKING SBS64/STR/P100 is a structural blind rivet with a locking stem, designed for high-load fastening applications where one-sided access is required. The rivet features a dome head, steel body, and steel mandrel, and conforms to IFI 134 standards. It delivers a tensile strength of 1,000 pounds and a shear strength of 1,300 pounds, making it suitable for structural joints in metal fabrication, construction framing, and equipment assembly. This fastener is installed by qualified fastener technicians, assembly mechanics, or tradespeople working with structural metal connections.

This rivet is suited for residential and commercial structural applications where a strong, permanent blind fastening is required. The size 64 designation indicates a 3/16-inch body diameter and a grip range of 0.062 to 0.270 inches, accommodating a variety of material stack-up thicknesses. Typical installation scenarios include steel framing, equipment panels, HVAC casings, electrical enclosures, and general sheet metal assembly. Each package contains 100 rivets.

Key Features

• Structural locking stem design provides high tensile and shear resistance in single-sided fastening
• Tensile strength of 1,000 pounds and shear strength of 1,300 pounds per IFI 134
• Steel body and steel mandrel for durable, corrosion-resistant structural joints
• Dome head profile with a 0.385-inch head diameter and 0.085-inch head height
• Grip range of 0.062 to 0.270 inches suits varied material thicknesses
• Compatible with No. 10 wire gauge drill size for consistent hole prep

Compatibility

Designed as an OEM-style structural blind rivet replacement for applications requiring IFI 134-compliant, size 64 dome head rivets with a 3/16-inch body diameter and locking stem retention.

Installation Notes

Install using a rivet tool rated for structural blind rivets; verify the drill hole diameter falls within 0.194 to 0.204 inches before installation. Ensure all mating materials are clamped securely within the grip range prior to setting the rivet. The locking stem is retained in the rivet body after setting - do not attempt to remove it, as it is integral to the structural holding strength. Follow applicable structural fastening codes and manufacturer torque or tooling specifications for the rivet gun being used.
