Rivetking /JK-0402/P25 6-32 Unc Rivet Nut Steel Zinc Pack 25

Product Description

The RIVETKING /JK-0402/P25 is a screwdriver-installed rivet nut designed for creating strong, load-bearing threaded inserts in thin sheet metal, panels, and structural members where access is limited to one side. Manufactured from steel with a clear zinc plating for corrosion resistance, this fastener accepts a 6-32 UNC thread and handles grip ranges from 0.06 inches to 0.085 inches. At 0.9 inches overall length with a 0.469-inch flange diameter, it seats flush and distributes clamp load across the panel surface. Each package contains 25 pieces. Installation requires only a standard flathead screwdriver, making it practical for field use without specialized tooling.

This rivet nut is suited for light-gauge metal fabrication, electrical enclosures, HVAC sheet metal panels, control cabinet assembly, and similar applications where a threaded fastener must be installed from a single side. It is appropriate for residential and light commercial work where 6-32 UNC threads are specified. Trades including HVAC technicians, electricians, and general sheet metal workers commonly use this fastener when retrofitting threaded attachment points into existing assemblies or fabricated components.

Key Features

• 6-32 UNC thread standard for broad compatibility with standard inch-series fasteners
• Screwdriver installation requires no specialty rivet nut tool - a flathead screwdriver is sufficient
• Clear zinc plating provides corrosion resistance for indoor and light-duty applications
• Grip range of 0.06 to 0.085 inches accommodates typical light-gauge sheet metal thicknesses
• 0.469-inch flange diameter distributes clamping force and prevents pull-through
• Package of 25 units suits both single-use service calls and small production runs

Compatibility

Designed as a single-side threaded insert for light-gauge steel panels and sheet metal applications requiring a 6-32 UNC thread with a grip range of 0.06 to 0.085 inches.

Installation Notes

Installation is performed by a mechanic or sheet metal technician using a standard flathead screwdriver. Ensure the panel hole diameter is correctly sized to match the 0.308-inch body diameter before inserting the nut. The fastener is a permanent insert once set; verify alignment and thread orientation prior to final installation. Follow applicable manufacturer guidelines and any relevant facility safety lockout procedures when working on energized enclosures or live assemblies.
