RHEEM UV12910 - 1inch 4500W Copper Non-Resistored Flange Element HWD (240V)

Product Description

The Rheem UV12910 is a one-inch, 4500W copper non-resistored flange element for high watt density applications, operating at 240V. This product serves as a direct replacement for Rheem, Ruud, and Richmond water heaters. It ensures uniform heat distribution for reliable and long-lasting performance.

• Wattage: 4500 W
• Voltage: 240 V
• Compatible with Rheem, Ruud, and Richmond water heaters

Product Highlights

This heating element is constructed from durable copper and includes a gasket along with clear installation instructions. It is UL and CSA listed for safety compliance, ensuring its reliable usage in various applications.

Product Information

Standard Information

• Type: Flange element
• Mounting Type: Flange

Technical Specifications

• Watt Density Classification: HWD
• Element Diameter: 0.260 inches
• Element Length (Flange to Tip): 13.68 inches
• Flange Hole Diameter (Four Places): 0.407 inches
• Flange Bolt Circle Diameter: 2.500 inches
• Resistored: No
