Product Description
The Rheem UV12895 is a screw-in heating element specifically designed for use in water heaters. This element operates at 240 volts and offers a power output of 3000 watts, effectively converting electrical energy to heat via resistive heating. The unit features a durable copper outer sheath, ensuring reliability during operation.
- Rated at 240 volts and 3000 watts
- Constructed with a copper outer sheath for durability
- Element length measures ten and one half inches
Product Highlights
The Rheem UV12895 heating element is vital for maintaining optimal water temperatures in water heaters.
Product Information
Standard Information
-
Brand: Rheem
-
MPN: UV12895
Technical Specifications
-
Input Voltage: 240 V
-
Wattage: 3000 W
-
Watt Density Classification: HWD
-
Watt Density at 240V: 182 W/sq. in.
-
Outer Sheath Material: Copper (with Plating)
-
Configuration: Straight
-
Element Diameter: 0.260 in.
-
Element Length - Flange to Tip: 10.56 in.
-
Element Length: 10.5 in.
-
Actual Thread Size - Outside Diameter: 1-9/32 in.
-
Nominal Thread Size: 1 in.
-
Thread Size: 1 1/4 in.
-
Threads per Inch: 11-1/2
-
Thread Type Series Designation: NPSM
-
Hex Head Size - Across Flats: 1-1/2 in.
-
Resistored: No
