Rheem SP210197 240V 3800W Lower Element

Product Description

The Rheem SP210197 240V/3800W Titanium Element is a genuine OEM replacement part. This element is designed for use with Rheem electric water heaters. The titanium outer sheath provides enhanced durability and resistance to corrosion, ensuring a long service life.

• Genuine Factory OEM repair part
• Titanium outer sheath material
• Foldback configuration

Product Highlights

This Rheem 240V 3800W titanium element is suitable for electric water heaters. It features a threaded mount and UNF connection type.

Product Information

Standard Information

• Brand: RHEEM
• Manufacturer Part Number: SP210197

Technical Specifications

• Watt Density Classification: LWD
• Input Voltage (V): 240
• Wattage at 240V (W): 3800
• Watt Density at 240V (W/sq. in.): 80
• Cold Resistance (ohms): 15.40
• Outer Sheath Material: Titanium
• Resistored: No
• Configuration: Foldback
• Element Diameter (in.): .316
• Element Length - Flange to Tip (in.): 14.00
• Mounting Type: Threaded
• Actual Thread Size - Outside Diameter (in.): 1-1/2
• Nominal Thread Size - (in.): 1-1/2
• Threads per Inch: 12
• Thread Type Series Designation: UNF
• Hex Head Size - Across Flats (in.): 1-7/8
• Manufacturer: Rheem
• Manufacturer #: SP210197
• Parts Town #: RHMSP210197
• Units: Each
• Brand: Rheem
• Item ID: SP210197
• Warranty: 1 year from date of delivery
• Product Type: Element
• Additional Part Number Information: Equivalent Part Number: SP210197
• Supplies Depot Part Number: 1497129
• Material: Titanium
• Dimensions: 0.32 in Dia x 14 in L
• Power Rating: 3800 W
• Voltage Rating: 240 V
• Connection Size: 1-1/2-12
• Connection Type: UNF
• Suitable For Use With: Rheem® Electric Water Heaters
