RHEEM AP13047E - 4500W Copper Non-Resistored Flanged Element MWD (240V)

Product Description

The Rheem AP13047E is a 4500W copper non-resistored flanged element designed for water heating tasks. It is suitable for use in Rheem and Ruud water heaters and operates at 240V. The copper construction allows for effective heat transfer, ensuring that water is heated efficiently and evenly.

• Wattage: 4500 Watts
• Voltage: 240V
• Material: Copper

Product Highlights

This flanged heating element features a foldback configuration for easy installation and efficient operation.

Product Information

Standard Information

• Product Type: Element
• Watt Density Classification: MWD

Technical Specifications

• Input Voltage (V): 240
• Wattage at 240V (W): 4500
• Watt Density at 240V (W/sq. in.): 128
• Outer Sheath Material: Copper (with Plating)
• Resistored: No
• Configuration: Foldback
• Element Diameter (in.): .260
• Element Length - Flange to Tip (in.): 11.88
• Mounting Type: Flange
• Flange Hole Diameter - Four Places (in.): .407
• Flange Bolt Circle Diameter (in.): 2.500
