Rheem AP12944 Flange Element - 7.68 in. 120V/1500W Copper Sheath

Product Description

The Rheem AP12944 is a flange-mounted heating element designed for water heating applications. With a length of seven point six eight inches, it operates at a voltage of one hundred twenty volts and provides one thousand five hundred watts of power. The copper sheath ensures effective heat transfer and durability.

• Flange bolt circle diameter: two point five inches
• Element length from flange to tip: seven point six eight inches
• Manufactured with a copper outer sheath for enhanced performance

Product Highlights

This element is ideal for installation in various water heaters, ensuring reliable and efficient heating. It meets standard specifications for heating elements in residential and commercial applications.

Product Information

Standard Information

• Input Voltage: one hundred twenty V
• Outer Sheath Material: Copper with plating

Technical Specifications

• Element Diameter: zero point two six inches
• Flange Bolt Circle Diameter: two point five inches
• Flange Hole Diameter (Four Places): zero point four one inches
• Watt Density at 120V: one hundred seventeen W/sq. in.
• Watt Density Classification: MWD
• Wattage at 120V: one thousand five hundred W
