Resideo Braukmann VCZAR1131 2-way 1 in fNPT VC Valve

Product Description

The Resideo Braukmann VCZAR1131 is a 2-way valve designed to manage water flow in heating and cooling systems. It is a 1-inch fNPT valve suitable for domestic and small commercial applications. This valve is part of the VC Series and works effectively with VC series On/Off actuators. The robust construction includes a bronze valve body and a cartridge made from reinforced plastic with a stainless steel spindle.

• Designed for effective control of water flow in heating and cooling systems.
• High pressure differential capability of up to 4 bar.
• Allows for easy replacement of components without draining the system.

Product Highlights

This valve is engineered for durability and designed to enhance system efficiency while providing reliable water flow control.

Product Information

Standard Information

• Brand: Resideo Braukmann
• MPN: VCZAR1131

Technical Specifications

• Cartridge Material: Ryton and Noryl Plastic
• Controlled Media: Water with maximum 50% glycol
• Approvals and Standards: CSA Certified
• Valve Body Material: Bronze
• Valve Body Pattern: Two-way, Straight Through
• Valve Cartridge: Yes
• Valve Flow Characteristic: Linear
• Valve Seat Material: EPDM O-ring seals on Noryl piston
• Valve Stem Material: Stainless Steel
• Valve Stem Travel: 0.4 in, 10 mm
• Connection Size: 1 in fNPT
• Cv: 6.6
