Resideo Braukmann T675A1524 Remote Bulb Commercial Temperature Controller

Product Description

The Resideo Braukmann T675A1524 is a remote bulb commercial temperature controller designed to manage air or liquid temperatures in various settings. This device is suitable for ducts, pipes, tanks, and boilers. It is particularly effective when the controller must be installed outside the sensing zone. Common uses of this controller include managing dampers and valves in heating, cooling, and heating-cooling systems. The ambient temperature compensation feature ensures stable temperature management.

• Regulates temperature of air or liquids in ducts, pipes, tanks, and boilers.
• Ideal for controlling temperature in areas outside the sensing range.
• Controls dampers and valves in HVAC systems.

Product Highlights

This controller is essential for efficient temperature control in commercial applications.

Product Information

Standard Information

• Brand: Resideo Braukmann
• MPN: T675A1524

Technical Specifications

• Application: Regulates temperature of air or liquids in ducts, pipes, tanks, and boilers
• Output Type: Relay
• Type: Remote Bulb
• Output: SPDT
• Voltage: 120 Vac or 240/277 Vac
• Frequency: 50, 60 Hz
• Dimensions: 5-5/8 inches high x 2 inches wide x 2-5/8 inches deep
• Sensor Element: Copper bulb
• Number of Sensor Inputs: 1
• Temperature Range: 55-175 degrees Fahrenheit
• Capillary Length: 20 feet
• Differential Temperature: 1 F fixed
