Resideo Braukmann Q651A1009 Multiple Switching Subbase

Product Description

The Resideo Braukmann Q651A1009 is a thermostat sub-base designed to work with T6051A thermostats and TG511 and TG512 thermostat guards. This sub-base allows for positive OFF switching for the HVAC system and features pressure-sensitive labels to help identify switching positions.

• Manual control options for Heat-Off-Cool and Heat-Off-Fan functions.
• Positive OFF switching capability for the system.
• Vertical or horizontal mounting on a standard outlet box.

Product Highlights

This product enhances thermostat functionality and supports efficient HVAC management.

Product Information

Standard Information

• Country of Origin: Import
• UPC: 085267071130

Technical Specifications

• Electrical Rating: 16 A @ 120Vac Full Load
• Electrical Rating: 8 A @ 240Vac Full Load
• Electrical Rating: 96 A @ 120Vac Locked Rotor
• Electrical Rating: 48 A @ 240Vac Locked Rotor
• Frequency: 60 Hz
• Suitable for Use With: T6051A Thermostat and TG511 and TG512 Thermostat Guard
• Standard/Approvals: CSA Certified, UL E4436, Guide #XAPX
• Pilot Duty: 124 VA
