Research Products 6202 2 Zone Control Panel

Product Description

The RESEARCH PRODUCTS 6202 is a single-stage, 2-zone HVAC control panel designed to manage zoned heating and cooling distribution in residential and light commercial systems. It coordinates damper operation and thermostat signals across two independent zones, allowing precise temperature management without the complexity of multi-stage or variable-capacity controllers. Licensed HVAC technicians install this panel as part of a complete zoning system, typically alongside zone dampers and low-voltage thermostats. Its straightforward single-stage design suits systems running conventional furnaces or air conditioners where two-zone separation is sufficient.

The 6202 is suited for residential forced-air systems and light commercial applications where splitting conditioned air into two independently controlled zones is required. It works within ducted HVAC installations where each zone has its own thermostat and motorized damper. This panel serves as the control hub that reads thermostat calls and opens or closes zone dampers accordingly, keeping each space at its target temperature without conditioning unoccupied areas unnecessarily.

Key Features

• Single-stage control logic compatible with conventional heating and cooling equipment
• Manages two independent zones from a single control panel
• Coordinates low-voltage thermostat signals with zone damper operation
• Compact panel design suited for installation in mechanical rooms or utility spaces
• Simplifies zoning without requiring multi-stage or variable-speed system support

Compatibility

Designed as an OEM-style replacement or new-installation control panel for single-stage, 2-zone ducted HVAC zoning systems.

Installation Notes

Installation should be performed by a licensed HVAC technician familiar with low-voltage control wiring and zoning system design. Power down the air handler or furnace and disable the thermostat circuit before making any wiring connections to the control panel. Follow applicable NEC requirements for low-voltage wiring routing and separation from line-voltage conductors. Verify all zone damper actuator wiring and thermostat connections against the panel wiring diagram before restoring power.

Technical Specifications

• Zones Supported: 2
• Control Stages: Single Stage

Standard Information

• Brand: RESEARCH PRODUCTS
• Manufacturer Part Number: 6202
