Regal Rexnord D604

Product Description

The Regal Rexnord D604 serves multiple functions as a flange fastener set, high torque disc pack assembly, or a refrigeration motor. Each component is crafted following original equipment manufacturer standards to ensure reliability.

• Can function as a flange fastener set, high torque disc pack assembly, or refrigeration motor.
• High torque disc pack assembly is compatible with medium and heavy-duty applications.
• Refrigeration motor operates efficiently at 115/230 volts and 1050 RPM.

Product Highlights

This product suits various industrial needs, making it versatile for technicians in HVAC or refrigeration.

Product Information

Standard Information

• Country of Origin: Mexico
• UPC: 662384156409

Technical Specifications

• Coupling Size: 604
• Component Type: Flange Fastener Set
• Style: KD10 and KD20
• Weight: 5.80 LB
• Packaged Length: 7.30 IN
• Packaged Width: 6.45 IN
• Packaged Height: 2.15 IN
• Number of Bolt Holes: 8
• Angular Misalignment: 0.25 °
• Disc Shape: Scalloped
• Torque Rating: 660,000 in/lbs
• Phase: 1
• Output Power (HP): 1/20 Hp
• Output Power (kW): 0.04 kW
• Input Voltage: 115/230 V
• Speed: 1050 rpm
• Service Factor: 1
• Frame Size: 42
• Enclosure: Semi Enclosed
• Thermal Protection: Thermally Protected
• Ambient Temperature: 40 °C
• Frequency: 60 Hz
• Current: 2.8/1.4 A
• Duty: Continuous Air Over
• Insulation Class: A
• UL: Recognized
• CSA: Y
• CE: N
• Number of Speeds: 1
• Electrical Type: Shaded Pole
• Starting Method: Across The Line
• Poles: 6
• Rotation: Clockwise Shaft End
• Mounting Type: Resilient Rings
• Motor Orientation: Horizontal
• Drive End Bearing: Sleeve
• Opp Drive End Bearing: Sleeve
• Frame Material: Rolled Steel
• Shaft Type: Flat
• Overall Length: 8.87 in
• Frame Length: 3.67 in
• Shaft Diameter: 0.375 in
• Shaft Extension: 3.25 in
