REGAL REXNORD D2826 General Purpose Motor 1/3 HP

Product Description

The REGAL REXNORD D2826 is a 1/3 HP motor designed for furnace applications. It operates at 825 RPM with a voltage rating of 208-230V and a current rating of 1.90/1.20 AMP. This single-phase, 8-pole motor is built with a 48 frame and a TEAO (Totally Enclosed Air Over) enclosure.

• Rated at 1/3 HP, suitable for furnace applications.
• Operates on 208-230V with reversible rotation capability.
• Features a TEAO enclosure and stud mounting for versatile installation.

Product Highlights

Designed for continuous air over duty, the REGAL REXNORD D2826 motor provides reliable performance, supporting various installation orientations.

Product Information

Standard Information

• Brand: REGAL REXNORD
• MPN: D2826

Technical Specifications

• Rated Motor Output Power: 1/3 HP
• Rated Motor Voltage: 208-230V
• Rated Motor Current: 1.90/1.20 AMP
• Phase: 1
• Poles: 8
• Run Capacitor: 10 Mfd-370 Volts
• Frame: 48
• Enclosure: TEAO
• Mounting: Stud
• Approximate Weight: 15.6 lb
• Frame Material: Rolled Steel
• C-Dimension: 10.31
• Insulation Class: B
• Rotation: Reversible
• Duty: Continuous Air Over
• Orientation: Horizontal / Vertical
• Ambient Temperature: 40°C
• DE Bearing: BALL
• NDE Bearing: BALL
• Shaft Diameter: 0.5 inches
• Shaft Length: 5 inches
• Agency Approvals: CSA & UL
• Country of Origin: Mexico
• Warranty: 1-YEAR
