REGAL REXNORD 3871 Fan and Blower Motor 1/4 HP

Product Description

The REGAL REXNORD 3871 is a fan and blower motor with a 1/4 HP rating, ideal for fan coil and air conditioning systems. This motor runs on 115 volts and fifty to sixty hertz, spinning at a speed of 1625 RPM. It features an open air over enclosure, offering reliable performance and durability.

• 1/4 HP, single-phase motor at 1625 RPM.
• Designed for fan coil and room air conditioner systems.
• Includes thermal protection and open air over enclosure.

Product Highlights

This motor is engineered for continuous duty applications, ensuring efficient air movement in various systems.

Product Information

Standard Information

• Brand: REGAL REXNORD
• MPN: 3871

Technical Specifications

• Output HP: 1/4 Hp
• Voltage: 115 V
• Frequency: 60 Hz
• Current: 2.90 A
• Speed: 1625 RPM
• Poles: 4
• Frame: 48
• Enclosure: Open Air Over
• Insulation Class: B
• Thermal Protection: Thermally Protected
• Shaft Type: Flat
• Shaft Diameter: 0.500 inches
• Shaft Extension: 7.00 inches
• Overall Length: 20.00 inches
• UL Recognized: Yes
