Regal Rexnord 111333.00 Leeson 1 hp Motor (56 Frame)

Product Description

Regal Rexnord 111333.00 is a 1 hp single-phase motor rated 115/208-230 V and 3450 rpm. It is a 56-frame, totally enclosed non-ventilated (TENV) design for continuous duty at 60 Hz with a 1.0 service factor and 40 C ambient rating. The motor features rigid base mounting for fan and blower applications, a standard 5/8 inch shaft with keyway, capacitor start, ball bearings, and an epoxy enamel finish for environmental protection.

• 115/208-230 V single-phase motor, 1 hp, 3450 rpm, 60 Hz
• 56 frame, totally enclosed non-ventilated (TENV), continuous duty, 1.0 service factor, rated to 40 C
• Rigid base for fan and blower applications; 5/8 inch shaft with keyway, capacitor start, ball bearings, epoxy finish

Product Highlights

1 hp single-phase, 115/208-230 V, 3450 rpm; 56 frame TENV; rigid base for fan and blower use

Product Information

Standard Information

• Brand: REGAL REXNORD
• Manufacturer Part Number: 111333.00
• Country of Origin: USA

Technical Specifications

• Brand: Regal Rexnord
• Manufacturer: Regal Rexnord / Leeson
• MPN: 111333.00
• Model/Spec Number: C6C34NB16J
• Input Voltage: 115/208-230 V
• Phase: Single-phase
• Frequency: 60 Hz
• Output Power: 1 hp (0.75 kW)
• Speed: 3450 rpm
• Frame Size: 56 (NEMA 56Z)
• Enclosure: Totally enclosed non-ventilated (TENV)
• Duty: Continuous (CONT)
• Service Factor: 1.0
• Ambient Temperature Rating: 40 C
• Mounting Type: Rigid base
• Application: Fan and blower
• Shaft: 5/8 inch diameter with keyway; 3/4 inch deep hole drilled and tapped 1/4-20 UNC
• Start Type: Capacitor start
• Bearings: Ball bearing design
• Finish: Epoxy enamel finish
• Weight: 32 lbs
