Red-White Valve 247AB_1-1/2 LOW LEAD BRASS SWING CHECK

Product Description

The Red-White Valve 247AB_1-1/2 is a swing check valve designed for horizontal applications. Ideally suited for plumbing systems, this valve features a nominal size of one and a half inches. It is constructed from forged brass and meets various industry standards for safety and reliability.

• Nominal size of one and a half inches
• Forged brass construction
• Horizontal T-pattern design

Product Highlights

This valve provides excellent resistance to pressure and temperature fluctuations, suitable for a wide range of applications. Use it in residential or commercial plumbing systems to prevent backflow and ensure smooth fluid movement.

Product Information

Standard Information

• Manufacturer: Red-White Valve Corp
• MPN: 247AB_1-1/2

Technical Specifications

• Body Material: Forged Brass
• End Style: Solder Joint
• Inlet to Outlet Length: 4.48 inches
• Low Lead Compliance: No
• Nominal Size: 1-1/2 inches
• Pressure Class: 200 lb WOG
• Series: 247AB
• Temperature Rating: 450 degrees F
• Top to Inlet Center: 2.33 inches
• Trim Material: Brass
• Type: Horizontal T-Pattern
