Rectorseal M10592 Direct Drive Blower Motor 1HP 1075RPM 230V

Product Description

The RECTORSEAL M10592 is a single-phase, permanent split capacitor (PSC) direct drive blower motor rated at 1 horsepower and 1075 RPM. Designed for continuous duty, it operates on 230 volts and delivers three selectable speeds across an RPM range of 925 to 1200. The motor features open air-over (OAO) enclosure construction with sleeve bearings and reversible CW/CCW rotation, making it a practical fit for forced-air air handling applications. It is typically installed by licensed HVAC technicians during blower motor replacements or equipment upgrades in residential and light commercial systems.

This motor is suited for direct drive blower applications in forced-air heating, cooling, and air handling units. The three-speed configuration allows installers to match airflow to system requirements without additional external controls. Its reversible rotation adds installation flexibility when retrofitting units with varying blower wheel orientations. The auto thermal protection helps guard against overload conditions during continuous operation.

Key Features

• 1 HP continuous duty rating for sustained blower operation
• Three selectable speeds with RPM range of 925 to 1200
• Reversible CW/CCW rotation for flexible installation orientation
• PSC motor type for reliable, capacitor-assisted single-phase starting and running
• Auto thermal protection guards against overload and overheating
• Open air-over (OAO) enclosure allows airstream cooling during operation

Compatibility

Designed as an OEM-style direct drive replacement motor for residential and light commercial forced-air blower applications requiring a 1 HP, 1075 RPM, 230-volt, 3-speed PSC motor with reversible rotation.

Installation Notes

Installation should be performed by a licensed HVAC technician. Disconnect and lock out all electrical power to the air handler or furnace before removing the existing motor. Verify that the existing capacitor rating matches the replacement motor requirements before energizing, and replace the run capacitor if it is suspect. Confirm shaft orientation and rotation direction before securing the motor mount and reconnecting wiring.

Technical Specifications

• Horsepower: 1 HP
• Voltage: 230 volts
• Motor Type: PSC (Permanent Split Capacitor)
• Phase: Single
• RPM: 1075
• RPM Range: 925 to 1200
• Speeds: 3
• Number of Poles: 6
• Rotation: CW/CCW (Reversible)
• Duty: Continuous
• Thermal Protection: Auto
• Service Factor: 1.0
• Bearing Type: Sleeve
• Enclosure: OAO (Open Air-Over)

Standard Information

• Brand: RECTORSEAL
• Manufacturer Part Number: M10592
