Rectorseal 86693 Locking Refrigerant Cap Universal Silver EACH

Product Description

The RECTORSEAL 86693 is a universal locking refrigerant cap designed to seal standard Schrader service valves on central air conditioning units and mini-split systems. Each cap features a 1/4-inch thread and is engineered to help prevent refrigerant leakage, protecting technicians and building occupants from exposure to dangerous gases. Installation and removal require a special proprietary tool, reducing the risk of unauthorized access or accidental valve actuation. Caps are color-coded silver and embossed for fast visual identification in the field.

These caps are suited for HVAC technicians servicing residential and light commercial refrigerant systems, including split-system central air conditioners and ductless mini-splits. The universal fitment covers standard Schrader valve service ports commonly found across a wide range of equipment. Proper use at every service port helps prevent accidental refrigerant mixing between systems and limits liability exposure during and after service calls.

Key Features

• Locks onto standard Schrader service valve ports using a 1/4-inch thread

• Requires a special tool for installation and removal, deterring unauthorized access

• Color-coded silver and embossed for quick field identification

• Helps prevent refrigerant leakage and protects against inhalation of hazardous gases

• Universal fit covers central A/C units and mini-split systems

• Sold per piece

Compatibility

Designed for use on standard Schrader service valves found on central A/C units and mini-split systems. Universal thread sizing supports a broad range of residential and light commercial refrigerant line service ports.

Installation Notes

Installation and removal must be performed by a licensed HVAC technician using the required proprietary tool. Always recover or isolate refrigerant per EPA Section 608 requirements before working on service valves. Do not overtighten or force the cap onto a damaged valve core, as this may compromise the seal. Confirm the cap is fully seated and locked after every service call.

Technical Specifications

• Thread Size: 1/4 inch

• Color: Silver

• Recommended Use: Refrigerant lines in A/C or mini-split units

• Quantity: 1

• UPC: 021449866934

Standard Information

• Brand: RECTORSEAL

• Manufacturer Part Number: 86693
