Rectorseal 83909 Aspen Universal Mini Kit 100-250V (ASP-MO-UNI)

RECTORSEAL
Brand: RECTORSEAL
SKU: 83909
Availability: In Stock

Ships same day if ordered by 12 pm
$269.93
$269.93
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

Rectorseal 83909 is an Aspen universal-voltage mini condensate pump kit for mini-split and ductless HVAC applications. The unit operates on 100-250 V AC, consumes 16 W (0.17 A running), and is self-priming with a maximum lifting height of 49 feet and a flow rate of 3.2 gph. The kit includes both pan-mount and inline-style reservoirs and features modular terminals for fast electrical connection and gravity inlet operation.

  • Universal input voltage 100-250 V AC; power consumption 16 W, running current 0.17 A
  • Self-priming pump with maximum lift up to 49 feet and flow rate of 3.2 gallons per hour
  • Kit includes pump assembly, pan-mount and inline reservoirs, modular terminals and installation accessories

Product Highlights

Compact universal-voltage condensate pump kit for mini-split systems; self-priming with 49 ft lift and 3.2 gph flow; includes pan and inline reservoirs and modular terminals.

Product Information

Standard Information

  • Brand: RECTORSEAL
  • Manufacturer Part Number: 83909
Technical Specifications
Brand
Rectorseal
MPN
83909
Alternate Part Numbers
REC83909; ASP-MO-UNI
Model Name
Aspen Mini (Mini Orange series)
Product Type
Condensate pump kit
Input Voltage
100-250 V AC
Power Consumption
16 W
Running Current
0.17 A
Flow Rate
3.2 gph
Maximum Lifting Height
49 Feet
Maximum Temperature Rating
104 F
Sound Level
21 dB
Duty Cycle
Non-continuous
Dimensions (pump)
4-1/4 in L x 1-1/2 in W x 2 in H
Package Dimensions
10 x 7 x 4 inches
Weight
1.23 pounds
Material
Plastic
Power Source
AC
Batteries Required
No
Mounting Type
Pan-mount and inline-style reservoir included
Inlet Type
Gravity inlet
Terminals
Modular terminals for fast connection
Included Components
Pump assembly; inline reservoir with lid and sensor cable, float and filter; submersible pan-mount reservoir; inlet hose; connector and breather tubing; power cable assembly; fuse; cable ties; Velcro strips; installation manual
Electrical Contacts
3 A NC dry contacts (rated 5 A inductive at 230 VAC)
Electronics
Fully potted electronics
