Rab WP3FA150 WP3 Outdoor Wallpack 157 W (Wall Pack) WP3FA150

Brand: RAB
SKU: WP3FA150
Availability: In Stock

Ships same day if ordered by 12 pm
$485.33
$485.33
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

Rab WP3FA150 is a WP3 outdoor wallpack LED fixture delivering a 157 W output for wall-mounted exterior lighting. The fixture features a die-cast aluminum housing, tempered glass lens, IP65 wet-location rating, and a constant-current 0-10V dimmable driver. It operates on 120, 208, 240, or 277 V, provides multiple lumen packages (~21,514 to 23,223 lm), and has an LED life rating of 100,000 hours.

  • Fixture wattage: 157 W; input voltage: 120/208/240/277 V; constant-current driver with 0-10V dimming
  • Die-cast aluminum housing with tempered glass lens, IP65 rated for wet locations; mounts to wall
  • Selectable color temperatures (3000K/4000K/5000K), integrated photocell (can be disabled), ~137 lm/W efficacy

Product Highlights

High-output outdoor LED wallpack with 0-10V dimming, integrated photocell, IP65 enclosure, and 100,000-hour LED life

Product Information

Standard Information

  • Brand: RAB
  • Manufacturer Part Number: WP3FA150
  • Country of Origin: China
Technical Specifications
Brand
Rab
Manufacturer Part Number
WP3FA150
Model / Series
WP3 / WP3FA150
Type
Outdoor wall pack
Fixture Wattage
157 W
Input Voltage
120, 208, 240, 277 V
Driver Type
Constant current (Class 1); 120-277 V
Dimmable
0-10V dimming (dims to 10%)
Photocell
Integrated selectable photocell (can be disabled)
Lumens
21,514; 23,223; 21,438 lumens (varies by configuration)
Efficacy
Approximately 137 lumens/W
Input Current (Amperage Rating)
1.30 A, 1.00 A, 0.80 A, 0.60 A (depending on voltage)
Color Temperature
3000 K, 4000 K, 5000 K (field selectable)
Color Rendering Index (CRI)
80+
Housing Material
Die-cast aluminum
Lens Type
Tempered glass
IP Rating / Enclosure Type
IP65 (suitable for wet locations)
Mounting Type
Wall mount
Average Life / L70 Lifespan
100,000 hours
Dimensions
9 in H x 9.4 in W x 17.8 in D
Operating Temperature
-40 to 122 degrees F
Includes
Dimming driver; integrated photocell
Certifications / Listings
DLC Premium listed; UL Listed; IESNA LM-79 and LM-80 tested; RoHS compliant; BAA compliant
UPC / GTIN
192552004619
Vendor SKU
WP3FA150
Application
For wet locations / exterior wall-mounted lighting
Features
Field adjustable CCT; flicker-free diodes; selectable photocell; 0-10V dimmable
