Rab VXLED13DG Vaporproof LED Ceiling Mount 13W

Product Description

The RAB VXLED13DG is a vaporproof LED ceiling mount featuring superior thermal management and all die-cast aluminum construction. It has a 100,000-hour life based on LM-80 results and TM-21 calculations and a thermal shock-resistant frosted glass globe. This LED is suitable for wet locations and provides 729 lumens at 5000K.

• Superior Thermal Management (Patent Pending)
• All Die-Cast Aluminum Construction
• 100,000-hour life based on LM-80 results and TM-21 calculations

Product Highlights

This vaporproof LED ceiling mount offers long-lasting performance and durability in demanding environments.

Product Information

Standard Information

• Brand: RAB
• Manufacturer Part Number: VXLED13DG
• Country of Origin: Cambodia

Technical Specifications

• Watts: 13W
• Color Temp: 5000K (Cool)
• Lumens: 729 Lumens
• Efficacy: 48.3 lm/W
• Color Accuracy: 65 CRI
• L70 Lifespan: 100,000 Hours
• Type: Constant Current
• 120V: 0.13A
• 208V: 0.08A
• 240V: 0.07A
• 277V: 0.06A
• Input Watts: 15.1W
• Lifespan: 100,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations
• Temperature: The VXLED is rated for 40 C maximum ambient and -30 C minimum cold starting temperatures
• Cold Weather Starting: The minimum starting temperature is -40 F (-40 C)
• Ambient Temperature: Suitable for use in up to 95 F(35 C)
• Housing: Die-cast aluminum housing and driver housing
• Guard and Globe: Shot blasted guard with frosted globe
• Reflector: High quality hydroformed semi-specular aluminum
• Gaskets: High-temperature Silicone
• Finish: Natural shot blasted aluminum
• Green Technology: Mercury and UV free. RoHS-compliant components.
• Driver: Multi-chip single 13W high output long life LED Driver. Constant Current,100V-277V, 50/60 Hz., 100-240VAC.3-.15 Amps 277VAC.15 Amps. Will deliver 70% of its initial lumens at 100,000 hours based onlm-80 Tests.
• Surge Protection: 4 kV
• Mounting: Three 1/2" NPS conduit entry points
• Compliance: IESNA LM-79 & LM-80 Testing
• UL Listed: UL Listed Suitable for Wet locations as a Downlight
• Color Consistency: 7-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color
• Color Stability: LED color temperature is warrantied to Shift no more than 200K in color temperature over a 5-year period
• Color Uniformity: RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C38.377-2011.
• BUG Rating: B0 U3 G1
• Indoor Outdoor Usage: Outdoor
• Power Source: Corded Electric
• Control Method: Touch
• Light Source: LED
• Number of Light Sources: 1
• Voltage: 120 Volts
• Light Color: Cool White
• Lighting Method: LED
• Wattage: 13 watts
• Application: Wet Location
• Series: VX Series
• Average Life: 100000 HR
• Ballast Type: Constant Current
• Color Rendering Index (CRI): 65
• Color Temperature: 5000 K
• Fixture Wattage: 15 W
• Housing Finish: Natural
• Housing Material: Die Cast Aluminum
• Lamp Type: LED
• Amperage Rating: 0.13/0.08/0.07/0.06 A
• Lamp Wattage: 13 W
• Lens Type: Frosted Glass Globe
• Rated Power: 13W
• Mounting Type: Ceiling Mount
• Fixture Type: Non Removable
• Installation Type: Surface Mount
• Required Assembly: No
