Rab SR8H Field-Adjustable LED Strip 85W (8 ft) SR8H

Brand: RAB
SKU: SR8H
Availability: In Stock

Ships same day if ordered by 12 pm
$266.54
$266.54
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

The Rab SR8H is an 8-foot field-adjustable LED strip fixture (MPN SR8H) offering selectable wattages (45, 55, 65, 75, 85 W) and selectable color temperatures (3500K, 4000K, 5000K, 5700K, 6500K). It operates on 120-277V with a constant-current Class II driver, supports 0-10V dimming to 10%, and delivers up to 12,624 lumens with an L70 rated life of 100,000 hours. The fixture features a polycarbonate lens, galvanized steel housing, surge protection, and is UL listed for damp locations.

  • Field-adjustable wattage (45–85 W) and selectable CCT (3500K–6500K); delivers 6,551–12,624 lumens
  • 120–277V constant-current Class II driver with 0-10V dimming (dims to 10%); input watts 44.4–86.4 W
  • Polycarbonate lens and galvanized steel housing; surge protection (L-N 1 kV, L/N-G 2 kV); UL listed for damp locations

Product Highlights

8-foot field-adjustable LED strip with up to 12,624 lm, 120–277V operation, 0-10V dimming, UL damp-location listing, and 100,000-hour L70 life.

Product Information

Standard Information

  • Brand: RAB
  • Manufacturer Part Number: SR8H
Technical Specifications
Brand
Rab
Manufacturer Part Number
SR8H
Model
SR8H
Product Type
8 ft field-adjustable LED strip
Wattage (selectable)
45 / 55 / 65 / 75 / 85 W
Factory Default Wattage
85 W
Color Temperature (selectable)
3500K, 4000K, 5000K, 5700K, 6500K
Lumens
6,551 - 12,624 lm
Efficacy
139.6 - 147.7 lm/W
Color Rendering Index (CRI)
84 - 86 CRI
L70 Lifespan
100,000 Hours
Input Voltage
120-277V
Input Watts (range)
44.4 - 86.4 W
Driver Type
Constant Current, Class II, 120-277V, 50/60 Hz
Dimming
0-10V dimming, dims to 10%
Surge Protection
L-N 1 kV, L/N-G 2 kV
Lens
Polycarbonate lens (frosted option referenced)
Housing
Galvanized steel (painted)
Ambient Temperature Rating (Max)
122°F (50°C)
Cold Weather Starting
-4°F (-20°C)
Certifications
UL Listed; Suitable for damp locations; IESNA LM-79 & LM-80 tested; DLC listed (family)
Mounting
Surface mount standard; V-hooks and chain mounting available (accessories ordered separately)
Accessories
J-box adapter; SR VHOOK KIT (suspended); SR JOIN KIT (surface joiner)
Dimensions
94.5 in x 2.36 in x 2.79 in
Weight (manufacturer listed)
4.00 lb
SKU
469612
UPC
192552029698
