RAB LIGHTING Rab Lighting CS8 C-Strip Field Adjustable 88W (8 ft) CS8
RAB LIGHTING Rab Lighting CS8 C-Strip Field Adjustable 88W (8 ft) CS8

Rab Lighting CS8 C-Strip Field Adjustable 88W (8 ft) CS8

Brand: RAB LIGHTING
SKU: CS8
Availability: Out Of Stock
$295.08
$295.08
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

Rab Lighting CS8 is an 8 ft field-adjustable LED strip luminaire that offers selectable wattages of 88W, 64W, and 42W and selectable color temperatures of 3500K, 4000K, and 5000K. The fixture uses a constant-current Class 2 driver for 120-277V operation with standard 0-10V dimming (dims to 10%) and long-life LEDs rated to 100,000-hour L70. Housing is sustainable biocomposite resin with an acrylic lens and is suitable for damp locations.

  • Field-adjustable wattage: 88W / 64W / 42W and selectable CCT: 3500K / 4000K / 5000K
  • Constant-current Class 2 driver, 120-277V input with 0-10V dimming (to 10%); surge protection included
  • Sustainable biocomposite resin housing with acrylic lens; 100,000-hour L70 LED lifespan

Product Highlights

8 ft linear LED strip; 42/64/88W field-adjustable; 3500K/4000K/5000K selectable CCT; 120-277V constant-current driver with 0-10V dimming; sustainable biocomposite housing; 100,000-hour L70; UL and DLC listings.

Product Information

Standard Information

  • Brand: RAB LIGHTING
  • Manufacturer Part Number: CS8
  • Country of Origin: Cambodia
Technical Specifications
Brand
Rab Lighting
Manufacturer Part Number
CS8
Product Name
C-Strip Field Adjustable
Type
Constant current LED strip (C-STRIP)
Length
8 ft (96.06 in)
Dimensions
Length: 96.06 in; Width: 2.38 in; Height: 1.81 in
Weight
7.92 lb
Field Adjustable Wattage
88W / 64W / 42W (factory default 88W)
Input Watts
43.3 - 89.6 W
Selectable Color Temperature
3500K / 4000K / 5000K (factory default 4000K)
Delivered Lumens
6,769 - 13,480 lm
Efficacy
145.4 - 158.9 lm/W
Color Rendering Index (CRI)
84 - 86 CRI
L70 Lifespan
100,000 Hours
Input Voltage
120-277V, 50/60 Hz
Input Current
120V: 0.75A / 0.54A / 0.37A; 208V: 0.43A / 0.31A / 0.21A; 240V: 0.37A / 0.27A / 0.18A; 277V: 0.32A / 0.24A / 0.17A
Driver
Constant current, Class 2, 120-277V
Dimming
0-10V dimming standard (requires separate 0-10V DC circuit), dims to 10%
THD
4.61% at 120V; 10.91% at 277V
Power Factor
99.8% at 120V; 97.9% at 277V
Surge Protection
Differential mode: 1 kV; Common mode: 2 kV
BUG Rating
CS8 100%: B3 U3 G2; CS8 75%: B3 U3 G2; CS8 50%: B3 U3 G1
Mounting
Surface and suspended mount standard; end-to-end connections require conduit wiring; V-hooks available for suspended mounting
Housing
Sustainable biocomposite resin (coffee chaff, waste seashells, recycled plastic)
Lens
Acrylic lens
Finish
Naturally occurring beige speckled pattern
Operating Temperature Range
Minimum starting -4°F (-20°C); Maximum ambient 122°F (50°C)
Certifications
UL listed (damp locations); IESNA LM-79 & LM-80 tested; DLC listed; Trade Agreements Act Compliant
Country of Origin
Cambodia
Battery Backup (optional variant)
Battery backup available on CS8/E variant — 90 minutes emergency operation (light loss factors: 88W=0.27, 64W=0.36, 42W=0.54)
