QSC CORE NANO Q-SYS Network I/O Processor, AV Control, 8x AEC Processors, 64 64 Networked Audio Channels QLAN AES67

Product Description

The QSC CORE NANO is a networked audio, video, and control processor designed for smaller-scale installations across various settings, including corporate environments, higher education, and healthcare. The CORE NANO is part of the Q-SYS Ecosystem, extending its capabilities for applications that require lower network channel capacity. It offers purely network-based audio and control processing, making it suitable for diverse audio needs.

• 64x64 networked audio channels (Q-LAN / AES67)
• 8x acoustic echo cancellation (AEC) processors
• Supports USB AV bridging for integrated audio and video solutions

Product Highlights

The CORE NANO features a robust software-based engine that enables various functionalities, including video routing, paging, and control operations without requiring dedicated hardware.

Product Information

Standard Information

• Brand: QSC
• Country of Origin: Mexico

Technical Specifications

• Network Channels: 64x64
• AEC Processors: 8
• Dante Audio Channels: Up to 32x32
• Q-SYS Microphones Supported: Up to 3 (6 with license)
• Control Engine: Full-featured Q-SYS Control
• Power Supply: Internal
• Form Factor: 1U Half-width
• Mounting: Includes mounting hardware
