Pro-source PRO17816202PL Pleated Air Filter 16x20x2

Product Description

The PRO-SOURCE PRO17816202PL is a permanent, washable pleated air filter built for large particle removal in residential and light commercial HVAC applications. Constructed with a steel media and steel frame, this filter handles airflow up to 825 CFM at a maximum face velocity of 500 FPM. The nominal size is 16 x 20 x 2 inches with actual dimensions of 15.5 x 19.5 x 1.75 inches. Rated to 250 degrees F maximum operating temperature, it suits high-demand environments where a disposable filter would require frequent replacement. HVAC technicians and facility maintenance professionals install this filter in air handlers, furnaces, and return-air grilles where durability and reusability are priorities.

This filter is designed for large particle removal applications, capturing dust, lint, and similar coarse airborne debris. The washable construction makes it well suited for commercial settings, workshops, and residential systems with high particulate loads where ongoing filter replacement costs are a concern. The steel frame provides structural rigidity at elevated velocities, reducing the risk of blowout or collapse under sustained airflow. At a final resistance of 1 inch w.g., airflow restriction remains manageable within properly designed duct systems.

Key Features

• Washable and reusable steel media extends service life compared to disposable options
• Steel frame maintains structural integrity at airflow velocities up to 500 FPM
• 825 CFM airflow capacity suits standard residential and light commercial air handlers
• Maximum operating temperature of 250 degrees F allows use in higher-temperature ducted systems
• Nominal size 16 x 20 x 2 inches fits standard filter slots without modification
• Final resistance of 1 inch w.g. at rated FPM keeps static pressure impact predictable

Compatibility

Designed for large particle removal applications in ducted HVAC systems that accept a 16 x 20 x 2 inch nominal filter. Confirm actual filter slot dimensions against the listed actual dimensions of 15.5 x 19.5 x 1.75 inches before installation.

Installation Notes

Installation should be performed by a qualified HVAC technician or trained maintenance professional. Always shut down the air handler or furnace and de-energize the unit at the disconnect before servicing the filter. Insert the filter with the airflow arrow pointing toward the blower. When washing, allow the filter to dry completely before reinstalling to prevent moisture introduction into the duct system.
