Pro-source PRO11379 Pleated Air Filter 24x24x1 Merv 8

Product Description

The PRO-SOURCE PRO11379 is a pleated panel air filter designed for residential and light commercial HVAC air-handling systems. It measures 24 x 24 x 1 inches nominal, with actual dimensions of 24.0 x 24.0 x 23.5 inches (depth). Rated MERV 8, the synthetic media captures dust, pollen, mold spores, and other mid-range particulates while maintaining airflow up to 1,042 CFM at a maximum face velocity of 500 FPM. The wire frame provides structural rigidity, and the integrated frame design simplifies insertion into standard filter tracks. This filter is installed by HVAC technicians and facility maintenance personnel as part of routine filter-change service.

The PRO11379 suits standard 1-inch filter slots in residential forced-air furnaces, air handlers, and packaged HVAC units where a 24 x 24 x 1 inch nominal filter is specified. The MERV 8 rating makes it appropriate for general residential comfort filtration and light commercial applications where baseline particulate control is required. Initial resistance ranges from 0.06 in. w.g. at 74 FPM to 0.27 in. w.g. at 369 FPM, keeping system static pressure well within typical design limits during early service life. Final resistance rating is 1.5 in. w.g.

Key Features

• MERV 8 synthetic pleated media for mid-range particulate capture
• Rated airflow of 1,042 CFM with a maximum face velocity of 500 FPM
• Wire frame construction with integrated frame for secure, rigid fit in filter tracks
• Low initial resistance starting at 0.06 in. w.g. at 74 FPM
• UL 900 listed media
• Maximum operating temperature of 120 degrees F

Compatibility

Designed as an OEM-style replacement for residential and light commercial HVAC systems requiring a 24 x 24 x 1 inch nominal pleated panel filter in a standard ring-panel filter rack.

Installation Notes

Filter installation should be performed with the air-handling unit powered off and the system fan at rest. Confirm airflow direction marked on the filter frame aligns with system airflow before securing in the filter rack. Standard filter-change intervals apply; inspect more frequently in high-dust or high-load environments. No special tools are required, but follow applicable ASHRAE and local mechanical code requirements for filter specifications on commercial systems.
