Pro-source 6934002435PRO Stacking Solenoid Valve 2-way 24VDC

Product Description

The PRO-SOURCE 6934002435PRO is a 2-way, 2-position stacking solenoid valve designed for pilot-actuated control with an air pilot return. It operates on 24 volts DC and delivers a Cv rating of 12, supporting flow rates up to 176.58 cubic feet per minute. The valve handles inlet and outlet connections of 3/4 inch and is rated for working pressures up to 145 psi and temperatures up to 356 degrees F. It is suited for use in industrial fluid control systems where modular, stackable valve assemblies are required. Licensed plumbers, pipefitters, and industrial maintenance technicians are the primary installers.

This valve is rated for use with compressed air, hot water, and steam, making it a versatile component in process control, HVAC, and industrial automation applications. The 2/2 way steam series design fits into stacking manifold assemblies where individual valve stations control separate circuit branches. Its pilot-actuated mechanism and air pilot return configuration make it well-suited for systems where a dedicated electrical signal is maintained for actuation and pneumatic pressure handles the return stroke.

Key Features

• 2-way, 2-position valve configuration for straightforward on/off flow control
• Air pilot actuator with air pilot return — no spring return required
• Cv rating of 12 with flow capacity up to 176.58 cubic feet per minute
• Compatible with compressed air, hot water, and steam service
• Rated to 145 psi maximum working pressure and 356 degrees F maximum working temperature
• 3/4 inch inlet and outlet connections for standard pipe integration
• Stackable design for modular manifold assembly configurations

Compatibility

Designed for use with compressed air, hot water, and steam systems. Intended for stacking valve manifold assemblies requiring 2-way, 2-position pilot-actuated control at 24 volts DC with 3/4 inch port connections.

Installation Notes

Installation should be performed by a qualified pipefitter or industrial maintenance technician familiar with pneumatic and fluid control systems. Depressurize and de-energize the system completely before removing or installing any valve in the manifold stack. Verify that supply voltage, line pressure, and pilot air pressure all fall within the rated limits before commissioning. Follow applicable local codes and manufacturer manifold assembly instructions for port orientation and torque requirements on fittings.
