Pro-source 6918011045PRO 5-way Solenoid Valve Spring Return

Product Description

The PRO-SOURCE 6918011045PRO is a stacking solenoid valve designed for pneumatic control systems that use compressed air as the working medium. This 5-way, 2-position valve uses an internal pilot actuator with spring return action to direct airflow through its ported body. With a Cv rating of 0.600 and a maximum working pressure of 113 psi, it is sized for compact pneumatic circuits where space is limited but reliable directional control is required. At 0.28 pounds and measuring 3.88 inches in length, 1.36 inches in height, and 0.71 inches in width, it fits tightly into modular valve manifold assemblies. Pneumatic system technicians and automation maintenance professionals are the typical installers.

This valve is suited for use in industrial and commercial pneumatic automation applications where compressed air powers actuators, cylinders, or other directional control circuits. Its stacking body-ported design allows multiple valves to be ganged together on a common manifold base, reducing plumbing complexity. The 1/8 inch inlet and 1/8 inch outlet ports are standard for small-bore pneumatic circuits. Operating on 110V AC, it fits easily into standard control panel wiring schemes. Maximum working temperature is 122 degrees F, making it appropriate for typical indoor industrial environments.

Key Features

• 5-way, 2-position directional control for compressed air circuits
• Internal pilot actuation with spring return for fail-safe positioning
• Cv rating of 0.600 supporting flow up to 31.89 cubic feet per minute
• Stacking body-ported design compatible with modular manifold assemblies
• 1/8 inch inlet and outlet ports for compact pneumatic plumbing
• 110V AC coil voltage fits standard industrial control panel wiring

Compatibility

Designed for use with compressed air systems; intended as a modular stacking solenoid valve for pneumatic directional control manifold assemblies operating within the stated pressure and temperature limits.

Installation Notes

Installation should be performed by a qualified pneumatic systems technician or industrial maintenance professional. De-energize the control circuit and isolate the compressed air supply before servicing or installing the valve. Verify that the supply voltage matches the 110V AC coil rating before energizing. Follow applicable NFPA and local codes for pneumatic control system wiring and plumbing.
