Pro-source 6910002430PRO Stacking Solenoid Valve 2-way 24VDC

Product Description

The PRO-SOURCE 6910002430PRO is a stacking solenoid valve designed for pilot-actuated, 2-way, 2-position fluid control. It operates on 24 volts DC and features an air pilot return mechanism, making it well suited for automated pneumatic circuits where directional control of compressed air, light oil, or water is required. With a Cv rating of 12 and a flow capacity of 268.24 cubic feet per minute, this valve delivers substantial throughput for industrial and commercial applications. Licensed HVAC technicians, pipefitters, and industrial maintenance professionals typically handle installation and integration into manifold or valve island assemblies.

This valve is intended for use with compressed air, light oil, and water in systems requiring reliable 2-way directional control. Its stacking design allows it to be combined with other valves in a modular manifold configuration, which is common in pneumatic automation, process control, and fluid power panels. It handles a maximum working pressure of 145 psi and a maximum working temperature of 194 degrees F, covering a broad range of industrial operating conditions in both light manufacturing and commercial mechanical rooms.

Key Features

• Pilot actuated with air pilot return for reliable 2-position directional switching
• Cv rating of 12 with 268.24 cubic feet per minute flow capacity
• 24 volts DC coil voltage for compatibility with standard control circuits
• Stacking design supports modular manifold or valve island assembly
• 1-inch inlet and 1-inch outlet port sizing
• Rated for compressed air, light oil, and water service up to 145 psi and 194 degrees F

Compatibility

Designed for use with compressed air, light oil, and water systems requiring 2-way, 2-position pilot-operated directional control in stacking or modular valve configurations.

Installation Notes

Installation should be performed by a qualified pipefitter or industrial maintenance technician familiar with pneumatic and fluid power systems. Depressurize and de-energize the system completely before removing or installing any valve. Verify that the supply voltage matches the 24-volt DC coil rating before energizing the valve. Consult applicable fluid power system codes and the equipment OEM documentation for manifold port orientation and mounting torque requirements.
