Pro-source 5350223012PRO 5-way 2-position Air Valve

Product Description

The PRO-SOURCE 5350223012PRO is a 5-way, 2-position directional control valve designed for pneumatic circuit automation and fluid power applications. It uses an air pilot actuator with spring return to shift valve position, controlling the flow of compressed air through five ports. With a Cv rating of 0.340 and a maximum working pressure of 127.98 psi, this valve is sized for compact pneumatic control tasks. A 1/8 in thread connection keeps installation straightforward in tight manifold or inline configurations. Pneumatic system integrators, maintenance technicians, and automation specialists typically install this type of valve in industrial and commercial control systems.

This valve fits applications where a remotely piloted, spring-return directional control is required. Common use cases include actuating small pneumatic cylinders, controlling air-driven tooling circuits, and routing compressed air in automated machinery. The 5-way, 2-position configuration allows the valve to direct flow between two outlet paths from a single inlet, making it suitable for double-acting cylinder control or circuit switching in industrial automation panels. The compact body dimensions support dense panel layouts and manifold mounting arrangements where space is limited.

Key Features

• 5-way, 2-position spool valve configuration for directional flow control in pneumatic circuits
• Air pilot actuator with spring return for remote pneumatic switching and automatic reset
• Cv rating of 0.340 and flow capacity of 9.00 cubic feet per minute for compact circuit sizing
• Maximum working pressure of 127.98 psi suitable for standard shop-air and industrial supply systems
• 1/8 in thread connection for easy integration into manifold blocks or inline pneumatic plumbing
• Compact body profile measuring 2.91 inches tall, 1.26 inches wide, and 0.63 inches in length

Compatibility

Designed as an OEM-style replacement or direct-install 5-way, 2-position pneumatic directional control valve for compact compressed-air circuit applications requiring a 1/8 in threaded port connection and air pilot with spring return actuation.

Installation Notes

Installation should be performed by a qualified pneumatic systems technician or automation maintenance professional. Depressurize and lock out the compressed air supply before removing or installing any directional control valve in a live circuit. Verify that the pilot air supply pressure falls within the valve's rated operating range before applying system pressure. Follow applicable safety standards for pneumatic systems and ensure all threaded connections are properly sealed with appropriate thread sealant to prevent air leakage.
