Pro-source 5250225511PRO 5-way Push-pull Manual Air Valve

Product Description

The PRO-SOURCE 5250225511PRO is a 5-way, 2-position manually operated pneumatic directional control valve designed for compressed air circuit control in industrial and trade applications. It uses a push-pull palm button actuator with mechanical operation, requiring no electrical signal or pilot air to shift states. With a Cv rating of 0.976, this valve delivers consistent flow capacity for small-bore pneumatic actuators and cylinders. Ports are threaded NPT for straightforward integration into standard pneumatic plumbing. Licensed pneumatic or mechanical technicians typically install this valve in machine control panels, pneumatic fixtures, and air-operated equipment where manual operator control is required.

This valve fits applications where a technician or operator needs direct, tactile control over a pneumatic circuit without automation or solenoid involvement. The push-pull palm button actuation is well-suited for workstation fixtures, jigs, pneumatic presses, and manual assembly tooling in light manufacturing and maintenance environments. Its compact footprint makes it practical for panel mounting or inline installation in tight enclosures. The 5-way, 2-position configuration supports double-acting cylinder control with two distinct actuator positions.

Key Features

• 5-way, 2-position valve design supports double-acting cylinder or actuator circuits
• Push-pull palm button actuator provides direct manual mechanical operation with no electrical components
• Cv rating of 0.976 supports adequate flow for small pneumatic actuators
• NPT threaded ports for compatibility with standard pneumatic plumbing fittings
• Compact body measures approximately 1.38 inches wide and 1.02 inches in length for panel or inline mounting

Compatibility

Designed as an OEM-style replacement or new-installation manual pneumatic directional control valve for compressed air systems using NPT-threaded pneumatic plumbing components.

Installation Notes

Installation should be performed by a qualified pneumatic or mechanical technician familiar with directional control valve circuits. Depressurize and lock out the compressed air supply completely before removing any existing valve or making connections. Use thread sealant appropriate for pneumatic service on all NPT connections and avoid overtightening to prevent port cracking. Verify all downstream actuators are in a safe, known position before restoring air pressure and cycling the valve.
