Pro-source 2830053510PRO Hose Reel with Hose 1/2 in 35 Ft

Product Description

The PRO-SOURCE 2830053510PRO is a spring-retractable hose reel supplied with a 35-foot rubber hose. The reel retracts automatically when the hose is released, keeping work areas organized and the hose protected from kinks and tangles. Built from steel with a gray finish, the reel is rated to 300 psi maximum working pressure and handles temperatures from -22 degrees F to 158 degrees F. The hose has a 1/2-inch inside diameter with 1/2-inch NPT inlet and outlet connections. Licensed plumbers, HVAC technicians, and mechanical contractors install this unit in shops, equipment rooms, and service bays.

This reel is suited for air and water service in light industrial, commercial, and heavy-duty residential applications. The open-reel design allows easy hose inspection and drainage. A 35-foot hose length provides reach across most service bays and mechanical rooms without requiring hose extensions. The 1/2-inch NPT fittings are compatible with standard air and water supply lines found in most shop plumbing installations. The unit ships complete with the hose installed, reducing bench time before mounting.

Key Features

• Spring-retractable mechanism for automatic hose retrieval
• 300 psi maximum working pressure rated for air and water service
• 35-foot rubber hose with 1/2-inch inside diameter included
• 1/2-inch NPT inlet and outlet for direct connection to standard supply lines
• Steel open-reel construction in gray finish with red hose for high visibility
• Wide operating temperature range: -22 degrees F to 158 degrees F

Compatibility

Designed for air and water service applications using 1/2-inch NPT supply connections in shop, industrial, and commercial mechanical installations.

Installation Notes

Installation is typically performed by a licensed plumber or mechanical contractor. Shut off the air or water supply and depressurize the line before making any connections. Mount the reel to a structural wall or ceiling bracket capable of supporting the unit weight plus hose load. Confirm all NPT threaded connections are sealed with appropriate thread sealant and pressure-tested before returning the system to service.
