Pro-source 1910001230PRO Miniature Coalescing Filter 0.1 Micron

Product Description

The PRO-SOURCE 1910001230PRO is a miniature coalescing filter designed to remove oil aerosols, water droplets, and fine particulates from compressed air lines. Rated at 0.1 micron, it delivers high-efficiency filtration suitable for pneumatic tools, instrumentation, and process air applications that require clean, dry downstream air. The filter features a polycarbonate bowl with a metal guard for added durability and incorporates a semi-automatic drain to simplify maintenance. Maximum operating pressure is 145 psi. The 1/8 inches port size makes it well suited for small-bore pneumatic circuits and tight installation spaces.

This filter is intended for use in compressed air systems where oil carryover from upstream compressors must be controlled before air reaches sensitive downstream equipment. Typical applications include pneumatic control panels, laboratory air supplies, spray finishing systems, and point-of-use filtration on light industrial machinery. The miniature form factor fits installations where space is limited and a full-size filter body is not practical.

Key Features

• 0.1 micron filtration rating removes fine oil aerosols and particulates from compressed air
• 145 psi maximum operating pressure suits standard industrial compressed air systems
• 1/8 inches port size designed for small-bore pneumatic circuits
• Polycarbonate bowl with metal guard provides visibility into bowl while adding impact protection
• Semi-automatic drain simplifies condensate removal without full manual intervention
• Miniature body measures 2.36 inches wide by 5.31 inches high for compact installations

Compatibility

Designed as an OEM-style replacement or direct-fit addition for compressed air filtration systems requiring a 1/8 inches ported miniature coalescing filter at up to 145 psi.

Installation Notes

Installation is typically performed by a licensed pipefitter, pneumatic systems technician, or qualified maintenance professional. Depressurize and lock out the compressed air supply completely before removing or installing any filter in the line. Ensure the filter is oriented with the drain port facing downward to allow proper condensate collection and drainage. Verify that upstream and downstream connections are sealed with appropriate thread sealant in compliance with applicable pneumatic system codes.
