Prime-line Products PL7756 Spline Channel Pull Tab 6-pack

Product Description

The PRIME-LINE PRODUCTS PL7756 is a white plastic pull tab designed to install directly into the spline channel of window and door screen frames. These tabs give installers and service technicians a clean, reliable way to seat and remove screen spline without damaging the frame or spline material. Each tab fits into the channel groove and provides a firm grip point during screen installation or replacement. The PL7756 measures 15/16 inches at the bottom width, 1-1/16 inches in height, and 5/8 inches at the top width. Sold in a 6-pack, this quantity is well suited for multi-screen service calls or batch screen replacements.

These pull tabs are commonly used in residential and light commercial window screen and door screen applications. They are appropriate wherever a spline channel frame is in use and a secure, recessed pull point is needed. Screen installers, glaziers, and general contractors frequently stock these as a consumable supply item during new construction punch-out, screen repair, or seasonal screen changeout work.

Key Features

• Installs directly into the spline channel for a flush, secure fit
• White plastic construction resists corrosion and suits standard white screen frames
• Bottom width of 15/16 inches, height of 1-1/16 inches, top width of 5/8 inches
• Lightweight at approximately 0.034 pounds per 6-pack
• Sold in a 6-pack to support multi-screen service work

Compatibility

Designed as an OEM-style replacement pull tab for standard spline channel screen frames used in residential and light commercial window and door screen assemblies.

Installation Notes

Installation is performed by pressing the pull tab into the open spline channel groove by hand or with a standard screen installation tool. No power tools are required. Ensure the spline channel is clear of debris and old spline material before inserting the tab. When removing screens for service, avoid prying against the tab at sharp angles to prevent cracking the plastic body.

Technical Specifications

• Bottom Width: 15/16 inches
• Height: 1-1/16 inches
• Top Width: 5/8 inches
• Material: Plastic
• Color: White
• Package Weight: 0.034 pounds
• Pack Quantity: 6
• UPC: 00049793077561

Standard Information

• Brand: PRIME-LINE PRODUCTS
• Manufacturer Part Number: PL7756
