PRECISION ELECTRIC MOTOR SALES 6007LL

Product Description

The Precision Electric Motor Sales 6007LL is a three-phase, six-pole slip ring motor designed for crane applications. This motor operates at four hundred fifteen volts and fifty hertz, providing thirty-one kilowatts of output power at a speed of nine hundred seventy-eight rpm.

• Rated for S5 duty with up to one hundred fifty starts per hour.
• Totally enclosed, fan-cooled (TEFC) enclosure with IP55 protection.
• Features F/F insulation class for both stator and rotor.

Product Highlights

This motor is suitable for industrial lifting and hoisting tasks, especially in environments where reliability and performance are critical.

Product Information

Standard Information

• Brand: Precision Electric Motor Sales
• MPN: 6007LL

Technical Specifications

• Phase: 3
• Output Power: 31.0 kW (41.50 Hp)
• Input Voltage: 415 V
• Speed: 978 rpm
• Frame Size: KS225MB
• Enclosure Type: Totally Enclosed Fan Cooled
• Duty Cycle: S5
• Starts Per Hour: 150
• Current: 64.0 A
• Temperature Rise: 75/75 K
