Pps 26505 3 Inch Carbon Steel 90 Degree Press Elbow

Product Description

The PPS 26505 is a 3-inch carbon steel 90-degree press elbow designed for pressfit piping systems operating on water and compressed air lines. It uses an FKM elastomer seal and carries a 200 psi pressure rating across a service temperature range of 0 to 250 degrees F. This fitting is part of the Megapress XL product line and installs without open flame, threading, or soldering. Licensed plumbers and pipefitters use this elbow where a direction change is required in press-fit steel pipe runs. The press-end by press-end (P x P) configuration accommodates standard tool-driven crimping on both sides of the fitting.

This elbow is suited for residential and commercial mechanical systems carrying water or air. Typical applications include hydronic heating loops, chilled water distribution, compressed air headers, and similar non-gas wet and dry service lines. It is not approved for natural gas service under any circumstance. The 3-inch nominal size targets mid-to-large diameter piping installations common in commercial buildings and light industrial settings where press-fit speed and reliability are priorities.

Key Features

• 3-inch nominal press-fit by press-fit carbon steel construction
• FKM seal rated for water and air service
• 200 psi maximum working pressure
• Service temperature range of 0 to 250 degrees F
• 90-degree elbow geometry for directional changes in steel press piping systems
• No flame, no threading, and no soldering required for installation

Compatibility

Designed for use in Megapress XL carbon steel press-fit piping systems on water and air service lines. Not compatible with natural gas service.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter familiar with press-fit steel piping systems. De-pressurize and drain the line before removing or installing any fitting. Use only a press tool and jaw set rated and approved for this fitting size and system. Verify local plumbing code compliance before installation, as press-fit steel systems may have jurisdiction-specific requirements under the IPC or applicable mechanical codes.
