Pass & Seymour 695-G Grounding Three-Way Combination Switch with Pilot Light 15A

Product Description

The Pass & Seymour 695-G is a grounding three-way combination switch with a pilot light, rated at 15A. This device combines a switch and pilot light into a single unit. It is suitable for residential and hospitality applications. The switch is designed for indoor use and is tamper-resistant.

• Easily accessible break-off separate or common feed.
• Long-life red neon lamp in pilot light rated 1/25 Watt 125V.
• Side wire #12 and #14 AWG.

Product Highlights

Combination switch with pilot light for residential and hospitality applications. It features a tamper-resistant design and side wiring.

Product Information

Standard Information

• Brand: Pass & Seymour
• Manufacturer Part Number: 695-G
• Country of Origin: Mexico

Technical Specifications

• Depth: 1.15 in
• Height: 4.06 in
• Width: 1.32 in
• Material: Thermoplastic
• Product Line: Pass & Seymour
• Action: 3W,Pilot Light
• Actuator: Toggle Switch
• Amperage: 15 Amp
• Applications: Hospitality,Residential
• Connection Type: Side Wire
• Contact Configuration: N-O
• Contact Rating: 120 V
• Indoor Outdoor: Indoor
• Load Type: CFL,Fluorescent,Halogen,Incandescent,LED,Universal,Xenon
• Mounting Type: Wall Box
• Number of Gangs: 1
• Number of Poles: 3 Pole
• Number of Switches: 1
• Operating Cycles: 30000
• Operating Temperature: Maximum continuous +60degrees C, minimum -30degrees C
• Switch Type: Toggle
• Tc Connection: Side wire
• Type: Combination,Switch,Tamper-Resistant
• Voltage: 120 Volt
• Wattage: 0.04 Watt
• Brand: Legrand
• Sub Brand: Pass & Seymour
• 12-Digit UPC: 785007006162
• Product UPC: 78500700616
• Certifications: CULUS
