Product Description
The Pass & Seymour 15AC1-I is an industrial-grade toggle switch ideal for commercial and industrial settings. This single-pole switch features a robust toggle made from chemical, impact, and heat-resistant thermoplastic material. It includes a glass-reinforced back body and a nickel-plated brass strap, which improves corrosion resistance. The switch allows back and side wiring with screw terminals compatible with #14 to #10 AWG copper or copper-clad wire. It is designed for indoor use and is UL and cULus listed.
- Single pole, single throw toggle switch
- Back and side wire connection capability
- Suitable for wall box mounting
Product Highlights
The Pass & Seymour 15AC1-I provides reliable performance in demanding environments.
Product Information
Standard Information
-
Brand: Pass & Seymour
-
MPN: 15AC1-I
Technical Specifications
-
Type: Switch
-
Switch Type: Toggle
-
Number of Poles: Single Pole
-
Number of Throws: Single Throw
-
Amperage: 15 A
-
Voltage: 120 VAC, 277 VAC
-
Load Rating: 15 A @ 120/277 VAC
-
Connection Location: Back and Side
-
Wire Connection Type: Screw Terminals
-
Terminal Accommodation: #14 AWG - #10 AWG
-
Mounting Type: Wall Box
-
Application Sector: Commercial, Industrial
-
Indoor/Outdoor: Indoor
-
Material: Thermoplastic
-
Standard: UL 20, FEDSPEC
-
cULus Listed: Yes
-
cULus Listing Number: 140597
-
Product Depth: 1.073 inches
-
Product Height: 3.281 inches
-
Product Width: 1.32 inches
-
Number of Gangs: 1
-
Color: Ivory
-
Finish: Matte
-
Load Type: CFL, Fluorescent, Halogen, Incandescent, LED, Universal, Xenon
-
Requires Neutral Wire: No
-
Electrical Connection: Screw Terminal
-
Number of Switches: 1
-
Number of Ways: 1
-
Operation Method: On/Off
-
Port Type: Light Switch
-
Current Type: AC
-
Control Style: Switch
-
Decorative Style: Traditional
-
Features: Heavy Duty
-
Box Shape: Rectangular
-
Country/Region of Manufacture: United States
-
Application: Light Control
-
Chemical Resistant: Yes
-
Wall Plate Included: No
-
Warranty Type: 1-Year Limited Warranty
