Parlec 30-118 Tapping Adapter 1-1/4 in Numertap 300

Product Description

The PARLEC 30-118 is a quick-change tapping adapter designed for use with 1-1/4 inch taps in CNC machining and production tapping applications. Part of the NUMERTAP 300 Series, it accepts a tap with a 1.021 inch shank diameter and a 0.766 inch square drive size. The adapter features a 1.770 inch projection and a 2.830 inch flange diameter, with an outside shank diameter of 1.890 inches. It is installed by machinists and tooling technicians to provide accurate, repeatable tap alignment and reduce tap breakage in high-volume threading operations.

This tapping adapter is suited for production machining environments where quick-change tooling systems improve cycle times and reduce setup. The NUMERTAP 300 Series is a standardized quick-change tapping system used in vertical machining centers, drill presses, and tapping machines. It is appropriate for threading ferrous and non-ferrous materials in both job shop and high-volume production settings. Coolant-through capability is not included on this adapter.

Key Features

• Quick-change interface for fast tap swaps without full spindle teardown
• Accepts 1-1/4 inch tap with 1.021 inch tap shank diameter
• 0.766 inch tap square size for positive drive engagement
• 1.770 inch projection for clearance in typical workholding setups
• 2.830 inch flange diameter for secure, stable mounting
• Part of the standardized NUMERTAP 300 Series tooling system

Compatibility

Designed for use with the PARLEC NUMERTAP 300 Series quick-change tapping system, compatible with toolholders and tapping heads within the NUMERTAP 300 platform that accept a 1.890 inch outside shank diameter.

Installation Notes

Installation is performed by qualified machinists or tooling technicians. Ensure the spindle and machine are powered down and at a complete stop before changing or seating the adapter. Verify that the tap shank and square dimensions match the adapter specifications before tightening. Follow machine tool manufacturer guidelines for torque and retention when securing the toolholder assembly.
