Product Description
The Parker U341N05NH1C is a NAMUR solenoid valve. This valve operates in various process and industrial applications. It is ideal for controlling dry or lubricated air flow. The direct mount design promotes high flow capacity and explosion-proof functionality.
- 3- or 5-way valve configurations available.
- Operates on 120 VAC at 60 Hz.
- Constructed with aluminum body and FKM seals.
Product Highlights
This valve is suitable for both indoor and outdoor installations, including hazardous locations.
Product Information
Standard Information
-
Brand: Parker Fluid Control
-
MPN: U341N05NH1C
Technical Specifications
-
Item Name: NAMUR Solenoid Valve
-
Type: 2-Position, High Flow Direct Mount, Explosion Proof
-
Nominal Size: 1/4 in
-
Connection Type: NPT
-
Number Of Ports/Ways: 3 or 5-Way
-
Media: Air, Inert Gases, Dry or Lubricated Air
-
Pressure Rating: 37 - 150 PSI
-
Min Operating Pressure Differential: 37 psi
-
Max Operating Pressure Differential: 150 psi
-
Temperature Rating: 37 - 122 °F
-
Max Fluid Temperature: 122 °F
-
Orifice Diameter: 1/4 in
-
Body Material: Aluminum
-
Seal Material: FKM
-
Coil Insulation Class: H
-
Power Rating: 5 W
-
Input Voltage: 120/60V AC
-
Frequency: 60 Hz
-
Enclosure: NEMA 7, 9
-
IP Rating: 65
-
Electrical Connection: Hazardous Location Conduit
-
Industry Standards: CSA and FM Approval for Class 1, Groups A, B, C, D, and Class II, Groups E, F, G; Meets Ex m T4 Zone 1
-
Flow Coefficient: 1.2
-
Mounting: NAMUR
-
Valve Configuration: Normally Closed
-
Environmental Rating: Hazardous, Indoor, Outdoor, Washdown
-
Overall Dimensions: Height: 4-7/8 in, Length: 1-37/64 in, Width: 1-17/64 in
