Parker PRTE10 Pneumatic Time Delay Relay 0.1-3 Sec

Product Description

The PARKER PRTE10 is a pneumatic time delay relay configured for on-delay operation, designed for use in industrial control circuits where timed switching is required. It provides a timing range of 0.1 to 3.0 seconds, making it suitable for short-interval sequencing tasks. The relay uses a subbase mount configuration and features a normally closed (NC) contact form with a 2-pin connection. At 0.3 pounds, it is a compact control component installed by licensed electricians or industrial controls technicians as part of relay logic or machine control panels.

The PRTE10 is used in industrial and commercial control applications where pneumatic timing logic is required. Typical installations include machine tool sequencing, conveyor interlocks, and process control panels that use subbase-mounted relay assemblies. The on-delay function holds the NC contact in its normal state until the set time elapses after the input signal is applied, then switches the output. This timing behavior is commonly used to prevent simultaneous starts or to introduce controlled delays in multi-step automated sequences.

Key Features

• Pneumatic on-delay timing mechanism with a range of 0.1 to 3.0 seconds
• Normally closed (NC) contact form for fail-safe switching logic
• Subbase mount design for secure panel installation and easy replacement
• 2-pin connection for straightforward wiring integration
• Compact and lightweight at 0.3 pounds

Compatibility

Designed as an OEM-style replacement or direct-fit component for industrial control panels and relay logic systems that accept subbase-mounted pneumatic time delay relays with a 2-pin interface.

Installation Notes

Installation should be performed by a qualified electrician or industrial controls technician. De-energize and lock out the control panel before removing or installing the relay. Verify the subbase is properly seated and secured before restoring power. Consult applicable NEC requirements and equipment manufacturer documentation for wiring and mounting guidance.
