Parker P3YFA98DSCN Coalescing Filter 1 Inch Port

Product Description

The PARKER P3YFA98DSCN is a coalescing filter designed to remove liquid aerosols, oil mist, and fine particulate from compressed air and gas systems. It features a polypropylene bowl with a manual drain and delivers filtration down to 0.01 micron, making it suitable for applications requiring clean, dry air at the point of use. Rated to 254 psi maximum, this filter handles the pressure demands of industrial and commercial compressed air lines. The 1 inch port size accommodates standard piping found in production facilities, pneumatic control panels, and similar installations. Licensed contractors and industrial maintenance technicians are the typical installers.

This coalescing filter is used in compressed air distribution systems where oil contamination and liquid carryover must be controlled upstream of sensitive equipment, instrumentation, or pneumatic tools. It is well suited for industrial process lines, spray finishing systems, and automation equipment requiring high-purity air. The manual drain allows for periodic condensate removal as part of routine maintenance. Its 3.54 inch diameter and 13.38 inch overall height fit standard inline filter mounting configurations.

Key Features

• 0.01 micron filtration rating removes fine oil aerosols and liquid contaminants
• 254 psi maximum pressure rating suits high-pressure compressed air systems
• 1 inch port size for direct inline installation in standard piping
• Polypropylene bowl offers chemical resistance for compressed air service
• Manual drain for controlled condensate removal during maintenance
• Compact form factor at 3.54 inches diameter and 13.38 inches overall height

Compatibility

Designed as an OEM-style replacement coalescing filter for industrial compressed air filtration systems with 1 inch ported inline filter housings rated to 254 psi or lower.

Installation Notes

Installation should be performed by a qualified industrial maintenance technician or pipefitter familiar with compressed air system service. Depressurize and lock out the compressed air line completely before removing or installing this filter. Use appropriate thread sealant on port connections per system requirements and verify all fittings are leak-free before returning the system to service. Consult local mechanical codes for compressed air system requirements in your jurisdiction.
